High speed train line installation in Saudi Arabia

GH CRANES & COMPONENTS has installed several gantry cranes in Saudi Arabia for Copasa Arabia Co Ltd, for the high speed train line that goes from Mecca to MEDINA passing through Jeddah.

IMG_9792

We have worked in the Work Base 1, where the bigantry cranes that fuel the rail soldering line (they put together 50 metres long rails by means of special soldering and they form one 300 metres long rail) have been assembled.

Once soldered, they store it with the help of fixed gantries that have been assembled, which are 22 units.

IMG_9814 IMG_9812IMG_9804

It has also been carried out the assemblage of other two bigantries for the assemblage of track changes. Each of these bigantries carried 250 metres of armoured line.

At the same time, in Madinat Work base 4 the assemblage of two bigantries has been carried out, also for the assemblage of track changes, and a bridge crane in an industrial unit for motor material (locomotive maintenance, etc).

Gantry Cranes for our dealer in Saudi “Etihad Cranes”.

Some picture form installation and commission of the Gantries.  One of them Capacity 10+10Tm and 18mts height, and the other Capacity 100+50Tm and 21 mts height.
They were installed in Bilfal facilities in Yanbu (Saudi Arabia).

grua-portico-GH-EtihadCranes-01 Gantry-cranes-GH-EtihadCranes-02Gantry-cranes-GH-EtihadCranes-01
See more references

Grúas pórticos para Etihad Cranes.
Venta de kits con puesta en marcha de dos pórticos, para nuestro distribuidor en Arabia Saudí. Un de ellos de 10+10t y 18m de altura y el otro de 100+50t  y 21m de altura.
Se han montado en las instalaciones de BILFAL en la ciudad de Yanbu en Arabia saudí.
Ver más referencias

BILFAL Project in Saudi Arabia

Double-girder gantry kit 100 + 50t.

Client: BILFAL Heavy Industries Ltd.
Installation Location: Saudi Arabia

The main lift is performed by a 100 ton capacity trolley with a GHG lifting gearbox for a 18.4m hol and a double hook, which will go on a gantry of 30m span.

In the pictures you can see a 50 ton hoist with double girder GHF with simple hook and 18m hol which will perform the auxiliary lifting.

Both hoists have a work with a load summing limiter ALM-100N and work both independently and in synchronized.

_MG_8538 _MG_8545 Sigue leyendo
